Wuxi Sunking Power Capacitor Co., Ltd.

2022High and low temperature box equipment bidding and procurement

Bidding Notice/Bidding Invitation

Tender number: 2022-WXSJ-001

<span style="box-sizing: border-box; margin: 0px; padding: 0px; font-family: microsoft=" "="" color:="">

1. Bidding conditions

Bidder: Wuxi Sunking Power Capacitor Co., Ltd. The project has met the bidding conditions and is now open for bidding.

2. Bidding Project: 2022 High and Low Temperature Box Equipment Bidding and Procurement Project

3. Bidding scope: 1 set of high and low temperature box equipment

4. Bidding location: Meeting room of office building, No. 18 Chunhui Road, Wuxi SUN.KING

5. Bid opening time: August 1, 2022

6. Obtaining bidding documents

Anyone interested in bidding, please contact us before July 31, 2022 (excluding statutory holidays and statutory holidays), as follows:

Gu Minxiao, 13812515237

7. Submission of bidding documents

Deadline for submission of bidding documents: Please send the electronic version of the bidding documents and the encrypted version of the price to the following email address according to the following time:

Sent togmx@sunking-tech.com before 16:00 on July 31, 2022，

Please send the encrypted password of the price to the following email address: jiaoh@sunking-tech.com

The bidding documents and quotation sheets must be provided in paper form in one original and one duplicate.

High and low temperature box technical requirements

Due to test requirements, the technical department of Wuxi Sunking Power Capacitor Co., Ltd. needs to purchase a high and low temperature box. The equipment must be used under high voltage conditions. The specific technical requirements are as follows:

<span style="box-sizing: border-box; margin: 0px; 1. Working volume: 10m3 high and low temperature test chamber (length * width * height: 2000mm*2000mm*2500mm).

2. Temperature requirements:

2.1 Temperature range: -50℃～+100℃ (temperature adjustable);

2.2 Temperature deviation: ≤±1℃ (refers to the stable state when the test temperature reaches stability and the test time is about 2 hours or more);

2.3 Heating and cooling rate (under load): 5℃/min (average throughout the process), when the heating and cooling rate within the range of -40℃ ~ +55℃ is ≤3℃, the temperature can be heated and cooled linearly;

2.4 Equipped with a 24-channel temperature recorder, it can record data in real time and automatically upload it to the computer.

3. Humidity requirements

3.1 Humidity range: 20%~98%RH;

3.2 Humidity deviation: +2～-3% (＞75％RH), ±5% (≤75％RH).

4. The internal bottom plate load-bearing capacity of the high and low temperature box is ≥3000KG and can bear 3 tons without deformation.

5. High-voltage bushing: The high-voltage bushing is connected from the top of the box, and the voltage level is ≥10kV.

6. Remote monitoring: The central control instrument can be remotely communicated and managed with the computer. After connection, the operation of the equipment, temperature, humidity and other parameters can be continuously monitored through the computer.

7. Security Protection

7.1 The box has a certain explosion-proof ability;

7.2 Over-temperature protection alarm;

7.3 The observation window must use high temperature resistant explosion-proof glass;

7.4 Install a grounding copper plate inside the box.

Wuxi Sunking Power Capacitor Co., Ltd.

July 20, 2022
