Features
It is mainly applied in conventional flexible DC engineering, low-frequency transmission or converter valves for offshore wind power projects, circuit breakers, and SVG devices.
Parameters
| Item | Feature |
| Referenced standard | GB/T 17702 (IEC 61071) |
| Operation ambient temperature (℃) | -40~50 |
| Rated voltage (kV) | 1.0~4.0 |
| Rated capacitance (μF) | 2000~20000 |
| Capacitance deviation | 0%~+5% |
| Equivalent series inductance (nH) | ≤ 50nH |
| Service life (years) | ≥ 40 |
| Executive standard | IEC61071, GB/T17702, 3.6kv 300μF，2.8kv 7500、9000、15000μF |
